Production Scale Freeze Dryer

Specification

LYO Unit 0.5 1 2 3 5 7.5 10
Usable Shelf Area m² 0.54 1.08 2.16 3.24 5.40 7.56 9.72
Ice Capacity Kg 10 20 40 60 100 150 200
Vial Capacity (f22mm) Vials 1200 2400 4500 6700 11200 15700 20200
Vial Capacity (f16mm) Vials 2300 4500 8800 13000 22000 30800 39600
Shelf Dimension (L) Mm 450 600 900 900 1200 1200 1200
Shelf Dimension (W) Mm 300 450 600 600 900 900 900
No. of Shelf Loaf 4+1 4+1 4+1 6+1 5+1 7+1 9+1
Shelf Spacing mm 100 100 100 100 100 100 100
Power Supply kW 6 14 21 29 43 54 66
Cooling Water m³/hr N/A 5 6.5 10 13 16 20
Dimension (L) mm 1600 2200 3600 3900 4500 4700 5200
Dimension (W) mm 1100 1200 1750 2200 2300 2300 2200
Dimension (H) mm 2100 2500 2850 3100 3100 3400 3800
Approx. Weight ton 1.5 2 3 4.5 7 8.5 10
